| Camera | ||
|---|---|---|
| Image Sensor: | 1/3″ Progressive Scan CMOS | |
| Effective Pixels: | 1920(H)x1080(V) | |
| Signal System: | PAL/NTSC | |
| Minimum Illumination: |
Color: 0.05Lux@(F1.4,AGC ON) B/W: 0.005Lux@(F1.4,AGC ON) 0 lux with IR |
|
| White Balance: | Auto / Manual / ATW / Indoor / Outdoor | |
| AGC: | Auto/Manual | |
| BLC: | ON/OFF | |
| WDR: | DWDR | |
| Shutter Time: |
PAL: 1-1/10,000s NTSC: 1-1/10,000s |
|
| Day& Night: | ICR | |
| Digital Zoom: | 16x | |
| Privacy Masking: | 8 privacy masks programmable | |
| Auto Focus: | Auto / Semi-automatic / Manual | |
| Lens | ||
|---|---|---|
| Focal Length: | 4-120mm, 30X | |
| Zoom Speed: | Approx.3.0s(Optical Wide-Tele) | |
| Angle of View: | 58-1.7 degree(Wide-Tele) | |
| Minimum Working Distance: | 10-1500mm (Wide-Tele) | |
| Aperture Range: | F1.6 to F4.4 | |
| Pan & Tilt | ||
|---|---|---|
| Pan Range: | 360°endless | |
| Pan Speed: |
Pan Manual Speed: 0.1°-160°/s, Pan Preset Speed: 240°/s |
|
| Tilt Range: | -15°-90° (Auto Flip ) | |
| Tilt Speed: |
Tilt Manual Speed: 0.1°-120°/s, Tilt Preset Speed: 200°/s |
|
| Proportional Zoom: |
Rotation speed can be adjusted automatically according to zoom multiples |
|
| Number of Preset: | 256 | |
| Patrol: | 8 patrols, up to 32 presets per patrol | |
| Pattern: |
4 patterns, with the total recording time not less than 10 minutes |
|
| Power loss recovery: | Support | |
| Park Action: |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
|
| PTZ Position Display: | ON/OFF | |
| Infrared | ||
|---|---|---|
| IR irradiation distance: | 120m | |
| IR irradiation angle: | Adjustable by zoom | |
| Input & Output | ||
|---|---|---|
| Turbo HD Output: | 1 turbo HD1080p output, BNC | |
| General | ||
|---|---|---|
| RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive | |
| Menu Language: | English / Chinese | |
| Power Supply: | 24V AC | |
| Power Consumption: | Max. 30W(IR: 9W, Heater: 6W) | |
| Working Temperature/Humidity: |
-30 °C-65°C(-22°F-149°F) 90% or less |
|
| Protection Level: |
IP66 standard (outdoor dome) TVS 4,000V lightning protection, surge protection and voltage transient protection |
|
| Dimensions: | Φ220×353.4mm (Φ8.66”×13.91”) | |
