| Camera | ||
|---|---|---|
| Image Sensor: | 2MP CMOS Image Sensor | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 1928(H)*1088(V) | |
| Min. Illumination: | 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR | |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
| Lens: |
Motorized VF lens; 2.8 – 12 mm Angel of view: 35.1°-114.5° |
|
| Lens Mount: | φ14 | |
| Adjustment Range: | Pan: 0 – 340°, Tilt: 0 – 75°, Rotation: 0 – 355° | |
| Day& Night: | IR cut filter with auto switch | |
| Wide Dynamic Range: | 120dB | |
| Video Frame Rate: | 1080p@25fps/1080p@30fps | |
| HD Video Output: | 1 Analog HD output | |
| Synchronization: | Internal Synchronization | |
| S/N Ratio: | More than 62 dB | |
| Up the Coax: | Support | |
| Menu | ||
|---|---|---|
| Auto White Balance: | Auto/MWB | |
| BLC: | Support | |
| AGC: | Support | |
| Language: | English/Chinese | |
| Function: | Wide Dynamic Range; Digital Noise reduction; Mirror; SMART IR | |
| General | ||
|---|---|---|
| Operating Conditions: |
-40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
|
| Power Supply: |
12 VDC±15% -A: 12 VDC±15%, 24 VAC±15% |
|
| Power Consumption: |
Max. 4.5W -A: Max. 6.5W |
|
| IR Range: | Up to 30m | |
| Communication : |
Up the coax Protocol: HIKVISION-C(Coaxitron) |
|
| Dimension: | φ136 × 102 mm (φ5.35” × 4.02”) | |
